Double 4-gang touch glass light switch with roller shutter switch WSZ-22

Product description

Features:

wireless communication
touch buttons
switching lights on/off
2 relays to control two lighting circuits
2 relays to control the directions of lifting and lowering the roller shutters
the ability to change the backlit colour and display mode
the ability to change the brightness level 0-100%
mode of automatic adjustment of the brightness of the backlit to the lighting conditions of the room

Replace the traditional wall switches with glass and stylish ones from the DOUBLE series in order to control both the lighting, and any device connected to the SINUM smart home system.

Double 4-gang touch switch equipped with 2 relays and 2 sensor fields, allows you to control lighting or other devices connected to the switch directly from the place of installation.

In addition, it is equipped with 2 relays and 2 sensor fields, allowing you to control the roller shutters up and down connected to the switch directly from the place of installation. After adding and programming the WSZ switch in the EH-01 central device, it allows for remote control as well as adding scenes and actions. The sun is too bright or you want to feel like in a cinema to watch a movie? It's easy now!

Connect the roller shutter switch to the SINUM system and control the roller shutters from anywhere, as well as perform appropriate automations and scenes depending on the lighting conditions. Thanks to the EH-01 central device you can freely configure according to your needs.

Communication with the EH-01 central device is wireless.

Product parameters

Specification	Value
Communication	Wireless WTP 868MHz
Height	84.7 mm
Width	164 mm
Depth	37.2 mm
Power Supply	230 V AC
Power Consumption	1 W
Operating Temperature	5°C - 50°C
Number of Relay Outputs	4
Max Relay Load	4 A / 0.5 A
