Wired 2-gang touch glass switch WSS-22

Wired 2-gang touch glass switch WSS-22

Flush-mount installation

Our devices are designed with ease of installation in mind. They require flush-mount installation in a 60mm diameter box, ensuring an elegant appearance and a seamless fit with the wall.

  • Mounting Type: Flush-mounted
  • Required Box: 60mm diameter

Thanks to their precisely tailored design, the installation process is quick and straightforward. Our devices blend perfectly into any interior, offering modern design and functionality without unnecessary complexity.

* The visualization illustrates the installation process for the Double series devices.

Product parameters

Specification Value
Communication Wired TECH SBUS
Height 84.7 mm
Width 164 mm
Depth 37.2 mm
Power Supply 24 V DC
Power Consumption 1 W
Operating Temperature 5°C - 50°C
Number of Relay Outputs 4
Max Relay Load 4 A
