WS-02m

Wired 2-gang touch glass switch WS-02m

Product description

Features:

  • switching lights on/off
  • 2 relays to control two lighting circuit
  • the ability to change the backlit colour and display mode
  • the ability to change the brightness level 0-100%
  • mode of automatic adjustment of the brightness of the backlit to the lighting conditions of the room



Replace the traditional wall switches with glass and stylish ones from the SINGLE series in order to control both the lighting, and any device connected to the SINUM smart home system. 2-gang touch switch equipped with 2 relays and 2 sensor fields, allows you to control lighting or any device connected to the switch directly from the place of installation. After adding and programming the WS switch in the EH-01 central device, it allows for remote control as well as adding scenes and actions. The switch has a built-in LED indicating the device status (on / off). The user may adjust the backlit colour and brightness using the SINUM application. Communication with the EH-01 central device is wireless.

Product parameters

Specification Value
Communication Wired TECH SBUS
Height 84.7 mm
Width 84.7 mm
Depth 37.2 mm
Power Supply 24V DC
Current Consumption 1 W
Operating Temperature 5°C - 50°C
Number of Relay Outputs 2
Max Relay Load 4 A
